Atmel/Microchip SAM L22
SMART ARM-base_d Microcontrollers
Atmel SAM L22 SMART ARM-base_d Microcontrollers (MCUs) are ultra-low-power segment LCD microcontrollers using the 32-bit ARM® Cortex®-M0+ processor. These MCUs drive up to 320 LCD segments and range from 48- to 100-pins with up to 256KB Flash and 32KB of SRAM. The SAM L22 devices operate at a maximum frequency of 32MHz and reach 2.46 CoreMark®/MHz. The SAM L22 are ideal for a wide range of HMI, IoT and battery-powered applications.
Features
-
256KB of Flash and 8KB of SRAM
-
Up to 32MHz operating frequency
-
Up to 320 LCD segments addressable
-
Six serial communication modules (SERCOM) configurable as
-
UART/USART, including ISO7816, SPI or I2C
-
Four 16-bit timer/counters
-
One 24bit Timer with 4 capture/compare registers
-
32-bit Real-Time Clock and calendar
-
One 20-channel 12-bit ADC, 2x Analog Comparator
-
1.62V to 3.63V power supply
-
Full Speed USB Device
-
16-channel DMA and 8-channel Event System
-
AES, True Random Number Generator and Tamper Detection
-
Support for up to 256 touch channels
-
Easy pin migration from SAM D21 and SAMD20 and SAML21 devices
-
Supported by Atmel Studio, the Atmel Software Framework and the SAM L22 Xplained Pro kit
|
